3AX17 HDMI M TO DVI F

Product Description

DVI F to HDMI M Adapter – converts Digital DVI signals to HDMI Interface . This adapter converts only digital DVI signals – dose not support analog signals . This adapter is a passive converter and dose not do up scaling and down scaling . Enables to connect DVI Digital cable to Devices with HDMI Port .Supports bi directional conversion . Outer housing material- PVC Moulded , Dual Moulding – inner and Outer for better strength . Pin material – phosphor bronze , Plating : Gold plated , Resolutions Supported 1080 P 60 Hz . Supports HDCP , EDID , 3D , … Used for AV Integrations , pro audio like Audiotrium , meeting room , class rooms , hospitals , studio ……

Specification

DVI DIGITAL F PANEL MOUNT TO HDMI MALE ,
It CONVERTS DVI DIGITAL FEMALE INTERFACE TO HDMI MALE ,
IT HELPS TO CONNECT ANY HDMI DEVICE TO THE DVI DIGITAL CABLE.
Protects the port of the Devices ,
IT SUPPORTS RESOLUTION OF 1080 P,
IT CAN WORK BI DIRECTIONAL ( HDMI OR DVI ANY INTERFACE CAN BE INPUT OR OUTPUT) AVAILABLE SMALL AND COMPACT DESIGN ,
COLOUR – BLACK
Application presentation,desktops , laptop , display , projector interface conversion.

Connector A DVI F – Digtial
 Connector B HDMI male
Housing Dual Moulding PVC
Connector Pins Phosphor Bronze
Plating Of Pins Gold Plating
 Resolution Supported 1080 p 60 Hz
Bi Directional  Yes
Colour Black
Supports HDCP / EDID /3D.
Main Image
Small Image 1
Small Image 2
Small Image 3
Small Image 4
“
