Product Description

nT01BG24 USB C TO AF ACTIVE EXTENSION CABLE ENABLES TO CONNECT A USB DEVICES BEYOND 5 METERS WITHOUT SIGNAL LOSS . THE USB C ACTIVE EXTENSION CABLE SUPPORTS DATA TRANSFER SPEEDS UP TO 5 Gbps . THE CABLE IS BACKWARD COMPATIBLE WITH USB 1.1 and USB 2.0 DEVICES . USB C PORTS IS ON THE HOST SIDE AND THE A FEMALE IS FOR THE DEVICE . THERE ARE REPEATER PCB’S IN THE CENTER OF THE CABLE TO BOOST THE SIGNAL . IT HAS A DC POWER 5 V 2 AMPS INPUT PORT WHICH CAN GIVE POWER TO THE DEVICES WHICH REQUIRES HIGHER POWER RATING .THE CABLE IS PLUG AND PLAY . COMPATIBLE WITH WINDOWS , MAC AND ANDROID SYSTEMS . AVAILABLE LENGTHS FROM 5 METERS TO 50 METERS. APPLICATIONS MACHINE VISION ,VIDEO CONFERENCE CAMERA AND SPEAKERS , PRINTERS , SCANNERS , KEYBOARD



Specification

Meet USB 3.0 Standard , bandwidth can reach to 5 Gbps super speed
Uncompressed signal and the image quality is not distorted; Booster circuit connected on the cable for stable signals .
Cable gauge 24 / 22 awg of annealed copper .
Standard USB Type C interface on the host side and USB A Female on the Device side;
Plug and play, support hot plug;
External power 5 V 2 Amps , Backward Compatible : 2.0 v / 1.1v
Available length: 5-50 meters

Host USB C Port
Device USB A F port
Cable Copper
Version USB 3.0
Speed 5 Gbps
Power supply 5 v 2 A
Back ward compatibility 2.0/1.1
Available Lengths 5m – 50m
